The LMR®-600-DB coaxial cable from Times Microwave Systems® is a low-loss, high-performance 50 Ohms coaxial cable designed for outdoor applications. It features a foam dielectric and a double-braided shield, which provide excellent signal strength and protection against interference. The cable has a UV-resistant jacket and watertight braids for direct burial applications. With better bending and handling than smooth wall or corrugated hard-line cables, the LMR-600-DB cable is ideal for use in wireless communication systems and applications that require high power handling and low attenuation. It is available in a variety of lengths and connectors to meet your specific needs.
PART DESCRIPTION
Part Number | LMR-600-DB |
Application | Outdoor/Watertight |
Jacket | PE |
Colour | Black |
SPECIFICATIONS
Description | Unit | Value |
Diameter | mm | 14.99 |
Weight | kg/m | 0.2 |
Bend Radius : Installation | mm | 38.1 |
Bend Radius : Repeated | mm | 152.4 |
Bend Moment | N-m | 3.73 |
Tensile Strength | kg/m | 158.9 |
Flat Plate Crush | kg/mm | 1.07 |
Maximum Frequency | GHz | 8 |
Velocity of Propagation | % | 85 |
Dielectric Constant | NA | 1.32 |
Time Delay | nS/m | 3.83 |
Capacitance | pF/m | 76.6 |
Inductance | uH/m | 0.19 |
Shielding Effectiveness | dB | > 90 |
Inner Conductor | /km | 1.7 |
Outer Conductor | /km | 3.9 |
Voltage Withstand | Volts DC | 4000 |
Jacket Spark | Volts RMS | 8000 |
Peak Power | kW | 40 |
