PI-70-M-SMA
Flexible whip antenna with SMA-male
Flexible, conical steel helix moulded in flexible thermoplastic rubber. Optimum performance compared to physical dimensions. Tuned and tasted to ensure minimum SWR and optimum performance. High quality materials in a smooth and slender design. Designed for use with different connectors.
FEATURES
Flexible whip antenna, especially made for use on portable transceivers.
- Wide range of different connector options available to connect to various transceivers
- Designed for Private Mobile Radios (PMR), such as Teltronic, Motorola, etc
- Tunable to a specific frequency - see cutting diagram
ELECTRICAL SPECIFICATION
| Type | Antenna with SMA-male |
| Frequency (MHz) | 375 - 500 |
| Impedance | 50 ohm |
| VSWR | < 2.0 @ f.res |
| Gain | 0 dBd, 2.15 dBi |
| Polarisation | Vertical |
| Max. Input Power | 25 W |
MECHANICAL SPECIFICATION
| Color | Black |
| Height | Max. 290mm |
| Weight |
Max. 70g |
| Mount Place | On transceivers |
| Materials | PE, steel and copper |
| Operating Temperature | -40 to +70 °C |
